Tool Applications
The Split Dump Bailer efficiently retrieves this debris by using a split design that allows for easy dumping of collected materials at the surface. Additionally, it can be utilized to perform cleanout operations after well treatments, such as acidizing or hydraulic fracturing, to remove residual fluids and debris.
Design Features & Benefits
- Ensures durability in harsh environments, reducing maintenance needs.
- Customizable to fit various wellbore dimensions, enhancing versatility.
- Hexagonal flats provided for secure assembly and disassembly.
- Connection choices customized to meet specific customer preferences.
Technical Data
|
MAX OD (In) |
FISHNECK OD (In) |
CAPACITY PER FOOT (Litre) |
THREAD CONNECTION |
|
1.750 |
1.375 |
0.3 |
15/16-10 UN |
|
2.000 |
1.750 |
0.4 |
1-1/16-10 UN |
|
2.250 |
1.750 |
0.5 |
1-1/16-10 UN |
|
2.500 |
2.313 |
0.6 |
1-1/16-10 UN |
|
3.000 |
2.313 |
0.9 |
1-1/16-10 UN |
|
3.500 |
2.313 |
1.3 |
1-9/16-10 UN |
